Description
The 300Mbps Wireless N Access Point delivers fast, stable Wi-Fi ideal for streaming, online gaming, and smooth browsing. With multiple operation modes including Access Point, Client, Repeater, Bridge, and Multi-SSID, it adapts to a wide range of networking needs. Featuring detachable antennas, WPA/WPA2 encryption, and PoE support for flexible deployment up to 30 meters, it offers reliable wireless performance with easy setup and secure connectivity.
Dimensions
Height: 36 mm (1.4 in)
Width: 125 mm (4.9 in)
Depth/Thickness: 181 mm (7.1 in)
Technical Specifications
Wireless Standard: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency Band: 2.4–2.4835 GHz
Data Transfer Rate: 300 Mbps (11n), 54 Mbps (11g), 11 Mbps (11b)
Ports: 1 × 10/100M Ethernet (RJ45, Passive PoE supported)
Antennas: 2 × 5 dBi detachable omni-directional (RP-SMA)
Power Supply: 9VDC/0.6A, Passive PoE (up to 30 m)
Operating Modes: Access Point, Multi-SSID, Client, Repeater, Bridge with AP
Buttons: Power On/Off, WPS, Reset
Transmission Power: <20 dBm (EIRP)
QoS: WMM (Wi-Fi Multimedia)
Management: SNMP
Certifications: CE, FCC, RoHS
Features
300Mbps wireless N speeds for smooth streaming and gaming
Multiple operation modes for versatile deployment
Two detachable high-gain antennas for improved coverage
WPS button for quick and secure setup
Passive PoE support for flexible installation up to 30 meters
Robust wireless security with WPA/WPA2 encryption
Package Contents
Wireless Access Point TL-WA801ND × 1
2 × Detachable Omni-Directional Antennas
Power Supply Unit × 1
Passive PoE Power Injector × 1
RJ-45 Ethernet Cable × 1
Resource CD × 1
Quick Installation Guide × 1
Model Number(s)
WA801ND
