Description
The TP-Link AC750 Wireless Dual Band 4G LTE Router delivers fast, reliable internet by sharing your 4G LTE network with multiple devices. With dual-band Wi-Fi speeds up to 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz, it ensures smooth streaming, gaming, and browsing. Equipped with powerful LTE antennas for stable coverage and flexible LAN/WAN support, it offers seamless connectivity for both mobile and fixed-line broadband. Simply insert a SIM card for instant setup and enjoy secure, high-speed internet anywhere.
Dimensions
Height: 33.5 mm (1.32 in)
Width: 174 mm (6.85 in)
Depth: 124.5 mm (4.9 in)
Technical Specifications
Wireless Standard: IEEE 802.11a/n/ac (5 GHz), IEEE 802.11b/g/n (2.4 GHz)
Frequency Band: Dual Band (2.4 GHz & 5 GHz)
Data Transfer Rate: 300 Mbps (2.4 GHz), 433 Mbps (5 GHz)
Antennas: 2 × Detachable External 4G LTE Antennas
Ports: 3 × 10/100 Mbps LAN, 1 × 10/100 Mbps LAN/WAN, 1 × Nano SIM slot
Power Supply: 12V ⎓ 1A
Buttons: WPS/Reset, Wi-Fi On/Off
Network Compatibility
4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800 MHz)
TDD-LTE B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900 MHz)
Operating Modes
-
3G/4G Router Mode
-
Wireless Router Mode
Security
Encryption: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Firewall: DoS Protection, SPI Firewall, IP & MAC Binding
Guest Network: 2.4 GHz Guest Network × 1, 5 GHz Guest Network × 1
VPN: PPTP VPN, OpenVPN
Software Features
Protocols: IPv4, IPv6
Quality of Service: Traffic prioritization by device or application
WAN Types: Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual Access)
NAT Forwarding: Virtual Server, Port Forwarding, Port Triggering, DMZ, UPnP
DHCP: Server, Client List, Address Reservation
DDNS: TP-Link DDNS, DynDNS, NO-IP
Management: Local & Remote Management, Access Control, Reboot Schedule
Features
-
Shares 4G LTE internet with multiple devices at speeds up to 150 Mbps
-
Dual-band AC750 Wi-Fi for smooth streaming and gaming
-
Detachable LTE antennas provide stable connections and extended coverage
-
LAN/WAN port offers flexibility for wired broadband backup
-
Easy SIM card plug-and-play setup with no configuration required
-
VPN support and advanced firewall for secure browsing
Package Contents
-
AC750 Wireless Dual Band 4G LTE Router × 1
-
Power Adapter × 1
-
RJ45 Ethernet Cable × 1
-
Quick Installation Guide × 1
-
Nano SIM Card (required, not included)
Model Number(s)
MR200
