Description
The TP-Link 8-Port Gigabit Desktop Switch is a reliable 8-port Gigabit desktop switch designed to provide high-speed connectivity and simplified network expansion. Featuring full gigabit ports, robust PoE+ support, and advanced features like PoE Auto Recovery and extended transmission up to 250 m, it is ideal for powering IP cameras, access points, and IP phones. Its fanless design ensures silent operation, while the durable metal casing offers flexibility for desktop or wall-mounted installations.
Dimensions
Height: 25 mm (1.0 in)
Width: 158 mm (6.2 in)
Depth: 99 mm (3.9 in)
Technical Specifications
Ports: 8× 10/100/1000 Mbps RJ45 (Ports 1–8 support 802.3af/at PoE+)
PoE Output: Up to 30 W per port, total 62 W PoE budget
Switching Capacity: 16 Gbps
Packet Forwarding Rate: 11.9 Mpps
MAC Address Table: 4K entries
Jumbo Frame: 16 KB
Network Media:
• 10BASE-T: UTP Cat3/4/5, up to 100 m
• 100BASE-TX: UTP Cat5/5e, up to 100 m
• 1000BASE-T: UTP Cat5/5e/6 or above, up to 100 m
Power Supply: External power adapter (53.5 VDC / 1.31 A)
Max Power Consumption: 71.61 W (with PD connected)
Max Heat Dissipation: 243.47 BTU/h (with PD connected)
Fan Quantity: Fanless
Installation: Desktop or wall-mounted
Transmission Method: Store-and-forward
Certification: FCC, CE, RoHS
Operating Temperature: 0–40 ℃ (32–104 ℉)
Storage Temperature: -40–70 ℃ (-40–158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
Features
Eight gigabit ports with up to 16 Gbps switching capacity
Eight PoE+ ports delivering up to 30 W per port and 62 W total power budget
Extend Mode for PoE transmission up to 250 m on Ports 1–2
PoE Auto Recovery for automatic device rebooting
Silent, fanless operation for noise-sensitive environments
Durable metal housing with flexible mounting options
Advanced traffic management with 802.1p/DSCP QoS and IGMP Snooping
Energy-efficient green technology
Package Contents
TP-Link 8-Port Gigabit Desktop Switch ×1
Power Adapter ×1
Installation Guide ×1
Model Number(s)
LS108GP
