Description
The 300Mbps Wireless N Ceiling Mount Access Point provides reliable, high-capacity Wi-Fi ideal for small to medium-sized businesses. With Omada SDN integration, it supports centralized cloud management, zero-touch provisioning, and intelligent monitoring for simplified deployment and control. Featuring PoE support, easy ceiling or wall installation, advanced security features, and load balancing, it ensures stable performance and seamless connectivity for up to 100+ concurrent clients.
Dimensions
Height: 29.7 mm (1.2 in)
Width: 170.5 mm (6.7 in)
Depth/Thickness: 189.5 mm (7.5 in)
Technical Specifications
Wireless Standard: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency Band: 2.4 GHz (2.4–2.4835 GHz)
Data Transfer Rate: 300 Mbps (11n), 54 Mbps (11g), 11 Mbps (11b)
Ports: 1 × Fast Ethernet (RJ-45, Passive PoE supported)
Antennas: 2 × internal 4 dBi omni
Power Supply: 24V Passive PoE (PoE adapter included), Max. 2.8W
Operating Modes: Access Point
Buttons: Reset
Transmission Power: CE ≤19 dBm (EIRP), FCC ≤21 dBm
Mounting Options: Ceiling or wall (kits included)
Coverage: Up to 60㎡ (650 ft²)
Concurrent Clients: 100+
Certifications: CE, FCC, RoHS
Features
Integrated Omada SDN with cloud management and zero-touch provisioning
Multiple SSIDs (up to 8) with VLAN mapping
PoE support for flexible deployment
Captive portal authentication with multiple login options (SMS, Facebook Wi-Fi, voucher, etc.)
Advanced wireless security including WPA/WPA2-Enterprise, MAC filtering, and rogue AP detection
Load balancing to ensure stable Wi-Fi performance
Scheduling and automatic reboot options
Centralized management via Omada app, hardware or software controllers
Package Contents
300Mbps Wireless N Ceiling Mount Access Point EAP110 × 1
Passive PoE Adapter × 1
Power Cord × 1
Mounting Kits × 1
Installation Guide × 1
Model Number(s)
EAP110
