Description
The TP-Link Archer AX50 is an AX3000 dual-band Wi-Fi 6 router designed to deliver gigabit-class speeds and reliable performance for modern households. With up to 2402 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band, it supports smoother 4K/8K streaming, online gaming, and fast downloads. Powered by an Intel® Home Wi-Fi chipset, it ensures superior processing speed and efficiency. Featuring four high-gain antennas, Beamforming, and high-power amplification, it extends strong Wi-Fi coverage throughout the home. With TP-Link HomeCare™ security, advanced parental controls, USB 3.0 media sharing, and VPN support, the Archer AX50 provided a complete, secure, and high-performance solution before its retirement.
Dimensions
Height: 38.6 mm (1.5 in)
Width: 260.2 mm (10.2 in)
Depth/Thickness: 135.0 mm (5.3 in)
Technical Specifications
Wireless Standard: Wi-Fi 6 (IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2.4 GHz)
Frequency Band: Dual-Band (2.4 GHz and 5 GHz)
Data Transfer Rate: AX3000 (2402 Mbps on 5 GHz, 574 Mbps on 2.4 GHz)
Processor: Dual-Core CPU (Intel® Home Wi-Fi Chipset)
Ports: 1× Gigabit WAN, 4× Gigabit LAN (supports static link aggregation with 2× LAN ports)
Antennas: 4× Fixed High-Performance Antennas
Power Supply: 12 V ⎓ 2 A
Security: WPA, WPA2, WEP, WPA/WPA2-Enterprise (802.1x), SPI Firewall, Access Control, TP-Link HomeCare™ Antivirus and Parental Controls
Operating Modes: Router Mode, Access Point Mode
Compatibility: Any ISP (subscription required), Tether App, Web Browser Management
Wi-Fi Features: MU-MIMO, OFDMA, Beamforming, DFS, Airtime Fairness, 4 Streams, Guest Network, VPN Server (OpenVPN, PPTP), USB 3.0 file/media sharing (NTFS, exFAT, HFS+, FAT32), Apple Time Machine support
Features
-
AX3000 dual-band Wi-Fi 6 with up to 3 Gbps speeds
-
Intel® Home Wi-Fi chipset for Gig+ performance
-
Four antennas and Beamforming for extended coverage
-
Target Wake Time (TWT) for improved battery life of client devices
-
TP-Link HomeCare™ for antivirus, parental controls, and QoS
-
VPN server support for secure connections
-
USB 3.0 port for media sharing and private cloud storage
-
Compatible with Alexa for smart home voice control
Package Contents
TP-Link Archer AX50 Router × 1
Power Adapter × 1
RJ45 Ethernet Cable × 1
Quick Installation Guide × 1
Model Number(s)
AX50
