Description
The TP-Link TL-WA1201 AC1200 Wireless Access Point delivers reliable dual-band wireless connectivity for offices, schools, and home environments requiring stable high-speed networking. Designed with four high-performance antennas and advanced wireless security, this access point provides extended coverage, flexible deployment options, and dependable everyday performance for multiple connected devices. Its compact, durable housing and Gigabit Ethernet connectivity make it ideal for professional networking setups and modern wireless expansion.
Dimensions
Length: 225 mm (8.9 in)
Width: 145.5 mm (5.7 in)
Height: 37 mm (1.5 in)
Technical Specifications
Type: Wireless Access Point
Material: High-durability plastic housing
Color: White
Wireless Standard: IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz
Frequency: 2.4 GHz and 5 GHz
Signal Rate: 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz
Interface: 1 × 10/100/1000 Mbps Ethernet Port with Passive PoE Support
Antenna: 4 Fixed High Performance Antennas
Wireless Modes: Access Point, Range Extender, Client, Multi-SSID
Wireless Security: WPA3, WPA/WPA2, WPA-PSK/WPA-PSK2
Transmission Power:
• CE: <20 dBm (2.4 GHz), <23 dBm (5.15 GHz~5.25 GHz)
• FCC: <30 dBm (2.4 GHz & 5 GHz)
Quality of Service: WMM
Advanced Features: Captive Portal
Protocol Support: IPv4, IPv6
Buttons: Power On/Off, WPS, Reset
Power Supply:
• EU: 12V/1A
• US: 12V/1.5A
Certification: CE, FCC, RoHS
Features
● Dual-band AC1200 wireless speeds for smooth streaming and reliable network performance
● Four fixed high-performance antennas provide wider coverage and stronger signal stability
● Supports multiple operating modes including Access Point, Range Extender, Client, and Multi-SSID
● Gigabit Ethernet port with Passive PoE support allows flexible installation and deployment
● Advanced WPA3 security helps protect wireless connections and connected devices
● Captive Portal support ideal for guest access management in offices and business environments
Package Contents
● TP-Link TL-WA1201 Wireless Access Point × 1
● Power Adapter × 1
● RJ45 Ethernet Cable × 1
● PoE Power Injector × 1
● Quick Installation Guide × 1
System Requirements
● Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, 8, 8.1, 10
● macOS, NetWare, UNIX, or Linux
● Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Part Number(s)
TL-WA1201
