Description
The Hikvision DS-UPS3000 is a high-capacity uninterruptible power supply designed for enterprise and professional environments that demand reliable backup power. With built-in AVR, super fast charging, and a wide input voltage range, it ensures stable performance and maximum uptime. Featuring comprehensive protection against surges, overload, short circuits, and discharges, as well as an LCD display and USB connectivity for remote monitoring, this UPS provides both efficiency and convenience within the Hikvision ecosystem.
Dimensions
Height: 210 mm (8.27 in)
Width: 145 mm (5.71 in)
Depth: 412 mm (16.22 in)
Weight: 18.5 kg (40.8 lb)
Technical Specifications
Power Capacity: 3000 VA / 1800 W
Input Voltage Range: 140 VAC to 290 VAC
Input Frequency: 50/60 Hz self-adaptive
Plug Type: Schuko
Output Voltage Range: 210 VAC to 235 VAC
Output Frequency: 50/60 Hz ± 0.5 Hz self-adaptive
Transfer Time: ≤ 10 ms
Waveform: PWM
Outlet Type: Universal
Outlet Number: 4
Battery Type: 12 V / 9 Ah × 4 pcs, lead-acid battery
Recharge Time: 6–8 hours to 90% capacity
Typical Backup Time:
• 100 W load: 150 min
• 600 W load: 15 min
• 900 W load: 6 min
Interface: USB
Display: LCD (input voltage, output voltage, battery capacity, load level)
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity: 30% to 90% (non-condensing)
Compatibility
Compatible with: Hikvision security systems, networking equipment, servers, and critical IT devices
Features
Built-in AVR for voltage stabilization
Super fast battery charging
Wide input voltage range for flexible operation
Overload, short circuit, and surge protection
USB port for remote control and monitoring
LCD display for real-time system status
Package Contents
UPS Unit × 1
Power Cable × 1
User Manual × 1
Model Number(s)
DS-UPS3000
