Description
Compact refillable ink tank business printer designed for productivity and efficiency. Supports Wi-Fi, Ethernet, Cloud, and smart assistants with high duty cycle, low running costs, and robust paper handling.
Dimensions
Main Unit
Height: 186 mm (with trays retracted) / 187 mm (with trays extended)
Width: 374 mm
Depth: 380 mm (with trays retracted) / 510 mm (with trays extended)
Weight: 7000 g
Technical Specifications
Printer
Print Resolution: Up to 600 × 1200 dpi
Print Technology: 2 Print Heads + refillable ink tank system
Mono Print Speed: Approx. 15.0 ipm
Colour Print Speed: Approx. 10.0 ipm
First-Print-Out Time: Mono ~9 sec, Colour ~11 sec
Two-Sided Printing: Auto duplex (A4, Letter, plain paper)
Print Margins (min): Top 5 mm, Bottom 5 mm, Left 5 mm, Right 5 mm
Consumables and Yields
Ink Bottles: GI-45 (BK, C, M, Y)
Maintenance Cartridge: MC-G05 (User Replaceable)
Yield (Plain Paper): Black ~3,000 pages (Economy ~4,500), Colour ~3,000 pages (Economy ~4,500)
Paper Support
Paper Types: Plain Paper (64–105 g/m²), Canon Red Label Superior, Canon Oce Office Colour Paper, Photo Paper Plus Glossy II (PP-201), Photo Paper Pro Luster (LU-101), Photo Paper Plus Semi-gloss (SG-201), Glossy Everyday Use (GP-501), Matte (MP-101), Light Fabric Iron-on Transfers (LF-101)
Max Input: Cassette – 250 sheets (plain paper)
Paper Sizes: A4, A5, B5, LTR, LGL, B/M-Oficio, Foolscap, Executive, #10/DL/C5/Monarch Envelopes, 4 × 6", 5 × 7", 7 × 10", 8 × 10", Custom width 89–216 mm × length 127–355.6 mm
Paper Weight: Plain 64–105 g/m², Canon specialty papers up to ~265 g/m²
Scanner
Type: CIS Flatbed Colour Scanner
Optical Resolution: 1200 × 2400 dpi
Line Scanning Speed: Colour ~3.5 ms/line (300 dpi), Greyscale ~1.5 ms/line (300 dpi)
Scanning Depth: Colour RGB 16-bit/8-bit, Greyscale 16-bit/8-bit
Max Document Size: A4, Letter (216 × 297 mm)
Copier
Copy Speed: First Copy ~17 sec (colour), ESAT ~9.1 ipm (colour)
Copy Quality: 3 levels (High, Standard, Economy)
Multiple Copy: Up to 99 copies
Copy Functions: Document, Two-Sided Copy, 2-on-1, 4-on-1, Frame Erase (flatbed only), ID copy
Copy Zoom: 25–400%, Fit to page (A5→A4, B5→A4, A4→A5, A4→B5)
Interface
Display: 2.7-inch (6.7 cm) colour LCD touchscreen
Languages: 33 supported (including English, Japanese, French, German, Spanish, Portuguese, Chinese, Korean, etc.)
Connectivity: Hi-Speed USB (B Port), Ethernet (10/100 Mbps auto), Wi-Fi IEEE802.11 b/g/n/a/ac (2.4 GHz)
Wi-Fi Security: WPA/WPA2/WPA3 (TKIP/AES), WPA/WPA2/WPA3-EAP (AES), IEEE802.1X (EAP-TLS/EAP-TTLS/PEAP)
SMB Version Support: SMB3.0.0, SMB3.0.2, SMB3.1.1
TLS Support: 1.0, 1.1, 1.2, 1.3
Mobile Apps: Canon PRINT, Easy-PhotoPrint Editor, Creative Park
Smart Assistant Support: Amazon Alexa, Google Assistant
Software
Included: Printer Driver (download), IJ Printer Assistant Tool (download), Easy-PhotoPrint Editor (download)
Supported OS: Windows 7 SP1+, 8.1, 10, 11 (including ARM); Windows Server 2008 R2 SP1–2022; macOS 10.15.7–13+; Chrome OS
Mobile Systems: iOS, iPadOS, Android
Minimum Requirements: Windows – 1.5 GB or more, Mac – 1 GB or more; Display 1024 × 768 XGA
Physical Features
Noise Level: Approx. 46.5 dB(A)
Operating Environment: 5–35 °C, 10–90% RH (no condensation)
Duty Cycle: Up to 27,000 pages/month
Power Source: AC 100–240V, 50/60Hz
Power Consumption: Off ~0.1 W, Standby USB ~0.8 W, Standby all ports ~1.4 W, Copying ~21 W
Standby Timer: ~5 min 1 sec (Lot26 standard, cannot be changed)
Typical Electricity Consumption: 0.14 kWh
