Description
The Mercury 5000VA Automatic Voltage Regulator (AVR) Stabilizer A5000D provides reliable protection for your appliances by monitoring incoming electricity and regulating voltage fluctuations. It automatically steps up low voltage and steps down high voltage to safe levels, ensuring uninterrupted performance and safeguarding sensitive devices. With advanced protection features, wide input voltage range, and user-friendly displays, it is ideal for both home appliances and office automation systems.
Dimensions
Height: 210 mm (8.3 in)
Width: 310 mm (12.2 in)
Depth: 285 mm (11.2 in)
Weight: 15.2 kg (33.5 lb)
Technical Specifications
Capacity: 5000 VA
Power Factor: 0.6–0.8
Input
Normal Voltage: 220/230 VAC
Regulation Voltage Range: 100–260 VAC
Frequency: 50/60 Hz
Output
Output Voltage: 220/230 V ± 8% (within regulation voltage range)
High Cut Voltage: 260 ± 5 VAC
Low Cut Voltage: 100 ± 5 VAC
Frequency: 50/60 Hz (auto-sensing)
Safety Cycle Delay: 6 s / 180 s selectable
Voltage Regulation: ±8%
Number of Taps: 5 / 7 taps
Transformer Type: EI laminated transformer
Control Type: Relay type
Indicators
-
Green LED: Working
-
Red LED: Fault / Protection
-
Yellow LED: Delay
-
2 × Analog voltage meters
Protection
Breaker/Fuse: 32 A
Overcurrent: Auto shut down
Short Circuit: Auto shut down
Overtemperature Protection: Yes
Physical
Display: Analog meters + LED indicators
Noise Level: <35 dB
Cooling Mode: Natural air cooling
Features
-
Auto buck, boost, and normal switchover
-
Wide input voltage range for flexible operation
-
Automatic restart on AC recovery
-
User-friendly analog meter display with LED indicators
-
Overtemperature and short circuit protection
-
32A breaker for safe current management
-
Suitable for home appliances and office automation systems
Package Contents
-
Mercury 5000VA Stabilizer × 1
Model Number(s)
AVR-5000VA
